| Point Spacing (mm) | 1.25 | 1.538 | 1.86 | 2 | 2.5 | 3 | 4 |
| Module Resolution (W*H) | 256*128 | 208*104 | 172*86 | 160*80 | 128*64 | 64*64 | 104*52 |
| Max Power Consumption (W/m²) | 600 | 600 | 550 | 550 | 500 | 450 | 450 |
| Max Power Consumption (W/m²) | 600 | 600 | 550 | 550 | 500 | 450 | 450 |
| Average Power Consumption (W/m²) | 195 | 180 | 160 | 160 | 160 | 150 | 140 |
| | | | | | | |
| Module Size (mm) | 320*160 | | | Safety Features | GB4943 / EN60950 | | |
| Module Weight (kg) | 0.32 | | | Frame Rate (Hz) | 50 & 60 | | |
| Color Temperature (K) | 2000-9300 (optional) | | | Refresh Rate (Hz) | 16384 | | |
| Viewing Angle (Horizontal/Vertical) | 160°/160° | | | Refresh Rate (Hz) | 3840,1920/3840 | | |
| Light Point Center Distance Deviation | <3% | | | Color Processing bits | ≥13bit | | |
| Brightness/Color Uniformity | ≥97% | | | Life Span(hrs) | 100,000(hrs) | | |
| Contract Ratio | 8000:1 | | | Working Temperature/Humidity | -20~40℃/10~65%RH(No Condensation) | | |
| Input Voltage | AC186~264V,47-63 Hz,Module Input DC Voltage:4.5V-5V | | | Storage Temperature/Humidity | -20~40℃/10~65%RH(No Condensation) | | |
